Pinhole detector

Name & Model

PHD-1250A Pinhole detector

Function & characteristic

n         High sensitivity. Pinhole as small as Φ0.018mm /Φ0.013mm can be precisely found out.

n         High luminance light source. Use light source with specific optical characteristics to ensure the detector to be sensitive and reliable.

n         Automatic side follower assures a minimum detecting blind area.

n         Operate by touch screen. Humanized interface is easy to understand.

n         Multiple protection and alarm, makes operation more relieved.

n         On-line detecting, max speed up to 1500m/min.

n         Compact structure，takes minimum space.

Technical parameters

1）Detecting material：opaque plate such as steel, aluminum, copper, etc

2）Detecting width：300-1250mm

3）Detecting thickness：≤1.2mm

4）Detecting sensitivity：Φ0.018mm /Φ0.013mm

5）Speed：≤1500m/min

6）Power：AC220V±22V  50Hz±1Hz

7）Consumption：≤500W

8）Temperature：10℃-40℃

9）Relative humidity：10%-80%

Name & Model

PHD-1250B Pinhole detector

Function & characteristic

n         High sensitivity. Pinhole as small as Φ0.018mm /Φ0.013mm can be precisely found out.

n         High luminance light source. Use light source with specific optical characteristics to ensure the detector to be sensitive and reliable.

n         Automatic side follower assures a minimum detecting blind area.

n         Operate by touch screen. Humanized interface is easy to understand.

n         Accurate and reliable labeling. Use servo motor control and auto side follower to assure the accuracy and speed of the labeling.

n         Multiple protection and alarm, makes operation more relieved.

n         On-line detecting, max speed up to 1500m/min.

n         Compact structure，takes minimum space.

Technical parameters

1）Detecting material：opaque plate such as steel, aluminum, copper, etc

2）Detecting width：300-1250mm

3）Detecting thickness：≤1.2mm

4）Detecting sensitivity：Φ0.018mm /Φ0.013mm

5）Speed：≤1500m/min

6）Max dimension of label coil：Φ350×100

7）Power：AC220V±22V  50Hz±1Hz

8）Consumption：≤500W

9）Temperature：10℃-40℃

10）Relative humidity：10%-80%
